20 ft Expandable Modular Home

2nd Generation Premium Model

​

Modern • Expandable • Engineered for Comfort & Durability

​

Overview

Compact, elegant, and intelligently designed, the Ariyo 20 ft Expandable Modular Home unfolds from a single transportable unit into a spacious 38.6 – 40.2 m² modern living space.
Built with a fully galvanised steel frame and premium insulated panels, it offers exceptional strength, comfort and visual appeal.

Perfect for residential, Airbnb, lifestyle, and commercial use, it provides the flexibility of a relocatable structure with the quality of a permanent build — ready for delivery across New Zealand and worldwide.

​

Key Features

• Reinforced 2nd-generation frame – 14 base beams, 32 cm spacing for superior load capacity

• Fully galvanised, anti-corrosion structure for coastal and humid environments

• Higher ceiling (+100 mm) and expanded floor space for enhanced comfort

• 75 mm EPS wall & roof panels for thermal and fire protection

• Hidden hinges + flush floor design for a modern, seamless finish

• Double-glazed aluminium joinery with thermal break profiles & screens

• Bamboo ceiling and premium floor finishes for luxury interiors

• Fully integrated kitchen and bathroom with modern fixtures and LED lighting

• Pre-wired and pre-plumbed to AU/NZ, EU and US electrical standards

• Quick setup & easy relocation – expand and live within hours

​​

Technical Specifications

CategorySpecification

Folded Size5900 × 2200 × 2530 mm

Expanded Size5900 × 6540 mm (Luxury A) / 5900 × 6820 mm (Luxury B)

Internal Area≈ 38.6 – 40.2 m²

StructureFully galvanised steel frame + cast-iron supports

Walls / Roof75 mm EPS insulated panels

Flooring18 mm cement-fibre board + PVC or SPC finish

CeilingBamboo or wood-fibre panels

ElectricalLED system with AU/NZ, EU, US compliant switches & sockets

PlumbingPre-fitted for kitchen & bathroom

Setup Time≈ 1 day (3–5 people + forklift or crane)

Warranty3 years structural / 1 year fixtures & fittings

​

Interior Layout Options

• Open Plan – Flexible studio or office layout

• 1 Bedroom – Living area + kitchenette + bathroom

• 1 XL Bedroom – Spacious suite with bathroom

• 2 Bedroom – Shared bathroom and living area

• 3–4 Bedroom configurations on request

Optional upgrades include SPC flooring, bamboo wall finishes, under-floor heating, and accent lighting.

​

Exterior Upgrades

• Carved metal or brick/wood look cladding

• 100 mm EPS insulation upgrade (walls & roof)

• Flat or slope roof add-on for rain drainage

• Full glass curtain facade for luxury look & natural light

• Outdoor terrace extension with composite decking

• ​

Delivery & Installation

Each Ariyo Home is manufactured to order and tested before shipping.

• Production time: ~40–45 working days

• Delivery: Available nationwide & internationally

• Installation: Fast setup; connections by licensed tradespeople

• ​

Pricing & Inclusions

Starting from NZD 29,999.99 (base open-plan model)
Includes structure, interior finishes, doors, windows, electrical layout, and plumbing points.
Excludes delivery, site works, installation, service connections, and consents unless stated otherwise.

​

Council & Compliance

Regulations vary by country and region.
In New Zealand and Australia, any unit that is fixed to the ground or connected to services generally requires building consent.
Ariyo Homes supplies engineering drawings and technical documents to assist with approvals but cannot guarantee consent outcomes.
Buyers are responsible for confirming requirements with their local authorities.

​

Warranty & Customer Responsibility

• 3-year structural / 1-year fixtures & fittings warranty (covering manufacturing defects only).

• Warranty is void if modified, incorrectly installed, or connected to non-compliant services.

• The buyer is responsible for all consents, site preparation, licensed installation, and maintenance.

• Ariyo Homes is not liable for council decisions, ground issues, transport, or third-party workmanship.

• ​

Important Notice & Disclaimer

Building and installation requirements differ by region.
Any structure that is fixed to the ground, connected to utilities, or used as a permanent dwelling may require local approval.
Ariyo Homes provides documentation for guidance only and does not guarantee approval or compliance.
All installations must be completed by licensed tradespeople; site access, foundations, and safety are the buyer’s responsibility.
Prices exclude delivery, site works, installation, and consents unless otherwise stated.
